Product Overview
• High-output dual-head LED work light designed for demanding construction, industrial and maintenance applications
• Two 50W LED light heads provide a combined 11,000 lumens of bright, efficient illumination
• 10' adjustable stand/tower helps elevate light above the work area to reduce shadows and glare
• Heavy-duty all-steel construction with steel guards protects heads from job-site abuse
• Designed and branded by CEP (Construction Electrical Products), now part of Southwire’s temporary lighting line
Key Features
• Dual 50W LED heads – approximately 5,500 lumens per head, 11,000 lumens total
• 10' adjustable tripod/tower style support for elevated area lighting
• All-steel housing and frame – no plastic structural parts
• Low amp draw (approx. 0.47 A per head, under 1 A total at 120V)
• Long-life LED diodes rated up to 50,000 hours for reduced maintenance
• Wet-location rated for use in damp job-site conditions
• Integrated steel guards around heads for impact protection
• Wide, stable base designed for use on typical construction surfaces
• Includes 3-part assembly: LED dual head (9800DHA), stand section (574-1S) and mast/base component (574-1M)
Specifications
• Brand: CEP (Construction Electrical Products) / Southwire
• Model / Catalog Number: 9842
• Product Type: Dual-head LED tripod/tower work light
• Light Output: 11,000 lumens total (approx. 5,500 lumens per head)
• Wattage: 2 x 50W LED (100W total)
• Voltage: 120V AC (typical 110–125V branch circuit)
• Lamp Type: Integrated high-output LED
• Color: Industrial yellow frame with steel guards
• Construction: Heavy-duty all-steel frame and housing
• Height: Adjustable up to approximately 10 ft
• Mounting: Tripod / tower-style stand with wide, stable base
• Cord Type: SJTW or equivalent job-site grade power cord
• Cord Length: Approx. 10–12 ft (varies by configuration)
• Amp Draw: Approx. 0.47 A per head, less than 1 A total at 120V
• Environmental Rating: Listed for wet locations (suitable for damp job-site use)
• Lamp Life: Up to 50,000 hours (typical LED rating)
• Components: 9800DHA dual LED head, 574-1S stand, 574-1M mast/base
• Application Rating: Temporary job-site, industrial, and construction area lighting
Recommended Applications
• General area lighting for construction and renovation job sites
• Lighting large indoor spaces such as warehouses, shops and industrial plants
• Temporary lighting for build-outs, interior framing, drywall and finish work
• Maintenance and shutdown projects where portable, high-output light is needed
• Rental fleets supplying temporary lighting to contractors and industrial clients
Benefits
• 11,000 lumen output delivers bright, wide-area coverage from a single portable unit
• Dual-head design allows broad, even illumination to help reduce shadows in the work zone
• Rugged all-steel construction and guards withstand tough handling and transport
• Long-life LEDs reduce bulb changes and maintenance compared to halogen or HID units
• Wet-location rating and job-site cord/jacket make it suitable for real-world construction environments
• 10' adjustable stand puts light where it’s needed most while keeping fixtures off the floor and out of harm’s way
CEP 9842 50W Dual-Head LED 10' Tripod Work Light – 11,000 Lumen High Output
$933.53
/
